Tungsten wire hmanga siam a ni

High Purity and Fine Processing - 99.95% thianghlimna aia tam emaw, a tlukpui emaw leh 0.003-3.0mm in diameter neia siam, kan tungsten wire hi fabrication-a precision application atan a tha hle a, leh medical device-ah pawh a tha hle.

Material – Wire hian chakna ropui tak, corrosion tha tak leh high-temperature resistance, stable high resistivity, thermal leh electrical conductivity tha zawk, leh service life rei tak a pe a ni.

Easy to Store - Tungsten wire hi spool-ah felfai takin a inzawm a, filament sei tak chu a inrualrem a, tangle-free a ni. He design hian storage a ti awlsam a, i hnathawhna hmun a tifai a, hman laiin awlsam zawk a siam bawk.

Precision Dimensions leh Fine Finish - 0.003mm atanga 3.0mm thlenga diameter nei, he tungsten wire tha taka siam hi EDM, PVD/CVD coating, leh semiconductor siamna atan a tha hle.

Wide Application Range - Lab research, LED siamna, electron tube, vacuum furnace, damdawi hmanrua, leh automotive glass-electronics, aerospace, leh material science industry hrang hranga rintlaknaah hman a ni.

Grade & Chemical chi hrang hrang a awm

Pawl	W	K	Thianghlimna	Fe	Mo	Midangte chu
W11	99.99 aia tam emaw, a tlukpui emaw	0.0000-0.0010	0.01 aia tlem emaw, a tlukpui emaw a ni	0.0015 aia tlem emaw, a tlukpui emaw a ni	0.0015 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni
W31	99.95 aia tam emaw, a tlukpui emaw	0.0040-0.0055	0.04 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni	0.005 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni
W61	99.95 aia tam emaw, a tlukpui emaw	0.0055-0.0075	0.04 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni	0.005 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni
W91	99.95 aia tam emaw, a tlukpui emaw	0.0075-0.0090	0.04 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni	0.005 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni
W95	99.00 aia tam emaw, a tlukpui emaw	0.0030-0.0080	0.04 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni	0.005 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni

Size & Tolerance a ni

Wire diameter a ni (u m)	Wire rit zawng a ni Mg/200mm a ni	Wire segment atanga inthlak danglamna			Diameter a tolerance a ni
Wire diameter a ni (u m)	Wire rit zawng a ni Mg/200mm a ni	0	Ⅰ	Ⅱ	Ⅰ	Ⅱ
10<>	0.3<>	±2.5	±3.0	±4.0	-	-
10<>	0.98<>	±2.0	±2.5	±3.0	-	-
40<>	4.85<>	±1.5	±2.0	±2.5	-	-
80<>	19.39<>	±1.0	±1.5	±2.0	-	-
300<>	272.71<>	-	±1.0	±1.5	-	-
350<>	-	-	-	-	±1.5	±2.0
d>500	-	-	-	-	±1.0	±1.5

Grade & Chemical chi hrang hrang a awm

Pawl	W	K	Thianghlimna	Fe	Mo	Midangte chu
W11	99.99 aia tam emaw, a tlukpui emaw	0.0000-0.0010	0.01 aia tlem emaw, a tlukpui emaw a ni	0.0015 aia tlem emaw, a tlukpui emaw a ni	0.0015 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni
W31	99.95 aia tam emaw, a tlukpui emaw	0.0040-0.0055	0.04 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni	0.005 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni
W61	99.95 aia tam emaw, a tlukpui emaw	0.0055-0.0075	0.04 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni	0.005 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni
W91	99.95 aia tam emaw, a tlukpui emaw	0.0075-0.0090	0.04 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni	0.005 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni
W95	99.00 aia tam emaw, a tlukpui emaw	0.0030-0.0080	0.04 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni	0.005 aia tlem emaw, a tlukpui emaw a ni	0.002 aia tlem emaw, a tlukpui emaw a ni

Size & Tolerance a ni

Wire diameter a ni (u m)	Wire rit zawng a ni Mg/200mm a ni	Wire segment atanga inthlak danglamna			Diameter a tolerance a ni
Wire diameter a ni (u m)	Wire rit zawng a ni Mg/200mm a ni	0	Ⅰ	Ⅱ	Ⅰ	Ⅱ
10<>	0.3<>	±2.5	±3.0	±4.0	-	-
10<>	0.98<>	±2.0	±2.5	±3.0	-	-
40<>	4.85<>	±1.5	±2.0	±2.5	-	-
80<>	19.39<>	±1.0	±1.5	±2.0	-	-
300<>	272.71<>	-	±1.0	±1.5	-	-
350<>	-	-	-	-	±1.5	±2.0
d>500	-	-	-	-	±1.0	±1.5

Dilna hrang hrang

Pure tungsten products hi Furnace parts, Semiconductor Base Plates, Electron Beam Evaporation atana Components, lon implantation atana Cathodes leh Anodes, Capacitors Sintering atana Tubes/Boats, X-ray Diagnostics atana Targets, Crucibles, Heating Elements, X-ray Radiation Shielding, Sputtering atan te hman a ni nasa hle Target leh Electrode te a awm.

Professional manufacturing background nei Zhuzhou kingdon Industrial & Commercial Co., Ltd hian Tungsten leh Molybdenum products wire,filament,rod,bar,sheet te bakah an alloy products leh an deep processing products te pawh a pe chhuak thin. Company hian ram chhung leh ram pawn industry-ah hming tha tak a chang tawh a ni.

Thiltum bik

Customer te tana quality sang tak supply tur leh customer te tana value lian ber siam nan a rei ber tur!

Sense of worth tih hi a ni

Passion,integrity,initiative,innovation,win-hneh theihna tur strategy

ngaihtuahna enkawl dan

Company hian "Customer-centered " leh "Quality of the life" tih ngaihtuahna management a nei a !

Kan Rawngbawlna te

OEM/ODM Service a ni

Kan professional R&D dept. target price hrang hrang leh mamawh hrang hrang atan product hrang hrang a siam thei.

Sample service a thlawna pek theih a ni

Sample hi a thlawna lak theih a ni.

OEM sample, ni 7-10 chhungin a rawn thawn ang che.

FAQ

Midang zawhna i neih chuan ,min rawn biak la, chhanna kan pe nghal ang che!

01.I thil siam ber chu eng nge ni?

A siam chhuah ber chu Tungsten leh Molybdenum te an ni a, an alloy product te leh an deep processing product te wire,filament,rod,bar,sheet leh customized parts te pawh a tel.

02.I general delivery date chungchang hi eng nge ni?

A tlangpuiin hnathawh ni 10-20 chhung .

03.Enquiry kan thawn hnuah eng chen nge feedback i hmuh theih ang?

Working day atanga darkar 24 chhungin kan reply ang che.
